QCC74xM

Fully integrated, pre-certified, all-in-one, tri-radio system-on-chip with RISC-V processor for programmable connectivity

Qualcomm QCC74xM is a module consisting of a combo tri-radio chipset integrating 1x1 Wi-Fi 6, Bluetooth® 5.4 technology, and IEEE 802.15.4 (Thread) powered by a 32-bit RISC-V MCU that can run up to 325 MHz and optional stacked memory (pSRAM and/or NOR flash). The QCC743M module consists of the combo tri-radio QCC743-1/-4 chipset while the QCC748M module consists of the tri-radio wireless MCU QCC748-2/-3/-6 chipset.

Unlike other Wi-Fi/Bluetooth/15.4 combo modules on the market, QCC74xM has an integrated, powerful 32-bit RIS...

Product license agreement
Featured DocumentsQualcomm QCC74xM programmable 1x1 Wi-Fi 6, Bluetooth, and IEEE 802.15.4 module Product Brief

Benefits

default icon alt text
Full radio integration
QCC74xM integrates all radio required for IoT connectivity, 1x1 Wi-Fi 6, Bluetooth 5.4 (Low Energy with coded PHY), and IEEE 802.15.4 (Thread). It will support Matter over Wi-Fi, Thread, and Ethernet with Bluetooth Low Energy commissioning capability.
default icon alt text
High computing power
In addition to all radio integration, QCC74xM also has a powerful 32-bit RISC-V microcontroller that can run up to 325 MHz with a DSP and FPU at its core. It also has the option to add stacked memory like pSRAM and/or NOR flash to boost computing capability.
default icon alt text
High security
QCC74xM has a built-in security acceleration engine, supporting both symmetric and asymmetric algorithms. It provides security services like secure boot and secure debug, and can support public key acceleration and TRNG and QSPI (XiP) on-the-fly AES decryption. It has achieved PSA Certified Level One.
default icon alt text
Rich peripherals and multimedia support
QCC74xM has 35 GPIOs that can be multiplexed to support rich peripheral interfaces like QSPI, SDIO, SD card, SPI, UART, I2C, I2S, PWM, 12-bit ADC, 12-bit DAC, IR remote, RMII (10/100 Ethernet), CAN (ISO11898), DVP camera, and DBI display. It has built-in motion JPEG to support 720p video codec as well as MIC input with 8/12/16/22.05/24/32/44.1/48kHz audio sampling and speaker output.
default icon alt text
User-friendly development environment and tools
QCC74xM is provided with an open-source SDK available on CodeLinaro, along with a VS Code-based IDE and associated development kits.

Block Diagram

Features

  • Pre-certified modules for fast time to market
  • Full radio integration to address IoT connectivity needs
  • High-performance, 32-bit RISC-V MCU with large memory resource and stacked memory SiP option
  • Advanced hardware-based security featuring public key acceleration and TRNG and QSPI (XiP) on-the-fly AES decryption
  • Secure boot and secure debug
  • Rich peripheral interfaces, including Ethernet, CAN, etc.
  • Direct camera interface (DVP) and display control (DBI)
  • Multimedia features like motion JPEG (720p) and MIC and speaker support
  • Supports hostless and hosted (RCP and NCP) operational modes
  • Open-source support with SDK on CodeLinaro, VS Code IDE market extension, module, and associated development kits
Specifications
CPU
Name
RISC-V1
Clock Speed
325 MHz
Wi-Fi
Standards
802.11b, 802.11g, 802.11n, 802.11ax
Spectral Bands
2.4 GHz
Antenna Configuration
1x1
Bluetooth
Specification Version
Bluetooth® 5.4
Security
Features
Secure Boot, Cryptographic Accelerator, Qualcomm® Trusted Execution Environment & Services, Secure debug
SRAM
Density
484 kB2
  1. with DSP and FPU, 128KB ROM, 4Kb eFuse and 1/2/4KB OTP
  2. on-chip (32KB I-Cache and 16KB D-Cache)

EVK Variants

The QCC74xM EVKs come in variants based on QCC743M or QCC744M module that include a PCB antenna or an RF Connector:

Dev Kit Order Number Antenna Config Embedded Memory Extended Memory GPIOs Multimedia Features

QCC743M EVK

65-79672-1

EVK-QCC743M-1-01-AA

PCB Antenna

No

4MB Flash

Up to 19

No

65-79672-2

EVK-QCC743M-1-01-AB

RF Connector

No

4MB Flash

Up to 19

 No

QCC748M EVK

65-79674-7

EVK-QCC748M-6-01-0-AA

PCB Antenna

8MB PSRAM

16MB Flash

Up to 32

Camera & Display interfaces,

A/V codecs

USB 2.0

Note: to leverage the best experience for the product comparison table, please use the desktop to view content.

4 of 4 total products

Product

CPU

Clock Speed

Wi-Fi

Standards

Spectral Bands

Bluetooth

Specification Version

RAM

Density

SRAM

Density

Interfaces

Supported Interfaces

Premium Tier

QCC711
Active

32 MHz1

—

—

Bluetooth® 5.4

—

—

PWM
I²C
GPIO
Temperature sensor
SPI
UART
ADC
QSPI
Multi-function pin
Voltage comparators
LED driver

QCC730M
Sampling

60 MHz2

802.11b
802.11g
802.11n
802.11a

2.4 GHz
5 GHz

—

1.5 MB3

640 kB

Master I²C
15x muxed GPIO
Slave SPI
2-wire UART
Master QSPI

QCC730
Active

60 MHz2

802.11b
802.11g
802.11n
802.11a

2.4 GHz
5 GHz

—

1.5 MB3

640 kB

Master I²C
15x muxed GPIO
Slave SPI
2-wire UART
Master QSPI

Mid Tier

QCC74x
Active

325 MHz

802.11b
802.11g
802.11n
802.11ax

2.4 GHz

Bluetooth® 5.3

—

484 kB

PWM
I²C
up to 35x GPIO
RMII
DAC
SPI
SDIO
UART
I²S
ADC
QSPI
CAN

  1. each for Bluetooth Low Energy, Application & Security subsystem
  2. with FPU
  3. XiP over QSPI Flash
