Snapdragon X55 5G Modem-RF System

2nd generation 5G modem with integrated multi-mode support, designed to deliver breakthrough wireless performance and accelerate global 5G rollout.

The Qualcomm® Snapdragon™ X55 5G Modem-RF System is a comprehensive modem-to-antenna solution designed to allow OEMs to build 5G multimode devices for a new era of connected experi....

more

The Qualcomm® Snapdragon™ X55 5G Modem-RF System is a comprehensive modem-to-antenna solution designed to allow OEMs to build 5G multimode devices for a new era of connected experi....

more

The Qualcomm® Snapdragon™ X55 5G Modem-RF System is a comprehensive modem-to-antenna solution designed to allow OEMs to build 5G multimode devices for a new era of connected experiences.

The Snapdragon X55 5G Modem-RF System supports virtually any combination of spectrum bands and/or modes: 5G mmWave and sub-6 GHz, standalone and non-standalone modes, TDD an....

more

The Qualcomm® Snapdragon™ X55 5G Modem-RF System is a comprehensive modem-to-antenna solution designed to allow OEMs to build 5G multimode devices for a new era of connected experiences.

The Snapdragon X55 5G Modem-RF System supports virtually any combination of spectrum bands and/or modes: 5G mmWave and sub-6 GHz, standalone and non-standalone modes, TDD and FDD, spectrum sharing, LTE and legacy modes (3G, 2G). This is designed to enable OEMs to bring blazing fast connected devices to global networks in nearly any form factor.

Qualcomm Snapdragon is a product of Qualcomm Technologies, Inc. and/or its subsidiaries.

Featured Documents
Infographic 1

5G for many device categories

Designed to bring 5G to all connected devices: from mobile devices, such as smartphones or mobile hotspots, to fixed wireless devices, such as routers and CPEs, to Always Connected PCs, XR devices, cars, and more.

Unprecedented flexibility

Native support for 5G mmWave and sub-6 GHz, FDD and TDD, standalone and non-standalone, and 5G/4G spectrum sharing, to allow operators to flexibly maximize spectrum assets to deliver the best possible experience.

Comprehensive 5G solution

Paired with Qualcomm Technologies’ mmWave antenna module and comprehensive RF front-end portfolio, Snapdragon X55 is at the heart of a 5G NR modem-to-antenna solution that allows OEMs to rapidly develop 5G devices for global networks.

Up to 7.5 Gbps

The Snapdragon X55 5G Modem-RF System can provide a near-instant connection between the user and the cloud.

5G NR Multi-Mode Modem-to-Antenna Solution

Snapdragon X55 5G Modem

Feb 19, 2019

0:37

You deserve to be a Snapdragon Insider.

Snapdragon Insiders will get behind-the-scenes access, premium experiences and extra perks that only the Snapdragon Insiders program can deliver. Join our community to get the inside track and help us shape the future of Snapdragon.

Features

  • Integrated 5G to 2G multi-mode support

  • Supports virtually any available spectrum band, mode or combination

  • 5G/4G spectrum sharing

  • Enhanced network capacity with full-dimension MIMO (FD-MIMO) support

  • Multi-antenna mmWave beamforming architecture support

Specifications

Cellular Modem

Modem Name: Qualcomm® Snapdragon™ X55 5G Modem-RF system

Downlink LTE MIMO: 4x4 MIMO

Peak Download Speed: 7.5 Gbps, 2.5 Gbps

Multi SIM: 5G Dual SIM support

Peak Upload Speed: 3 Gbps, 316 Mbps

5G Technology: 5G NR

Downlink LTE Streams: 24 LTE streams

5G Spectrum: 5G/4G spectrum sharing, mmWave, sub-6 GHz

5G Modes: TDD, SA (standalone), NSA (non-standalone), FDD

Downlink QAM: Up to 1024-QAM

5G RF: 100 MHz envelope tracking, Adaptive antenna tuning

5G mmWave specs: 800 MHz bandwidth, 8 carriers, 2x2 MIMO

5G sub-6 GHz specs: 200 MHz bandwidth, 4x4 MIMO

Cellular Technology: LAA, LTE Broadcast, 5G NR FDD, 5G NR TDD, SA, NSA, WCDMA (DB-DC-HSDPA, DC-HSUPA), LTE FDD, LTE TDD including CBRS support, TD-SCDMA, CDMA 1x, EV-DO, GSM/EDGE

Uplink Technology: Uplink Data Compression (UDC)

Downlink Carrier Aggregation: 7x20 MHz carrier aggregation

Uplink Carrier Aggregation: 3x20 MHz carrier aggregation

RF

RFFE: 5G envelope tracking, 5G adaptive antenna tuning

    Compare related products.

    Downlink LTE MIMOPeak Download SpeedPeak Upload Speed5G Technology5G Spectrum5G ModesDownlink QAM5G RF5G mmWave specs5G sub-6 GHz specsmmWave FeaturesUplink TechnologyDownlink Carrier AggregationUplink Carrier AggregationRFFE
    4x4 MIMO
    7.5 Gbps
    2.5 Gbps
    3 Gbps
    316 Mbps
    5G NR
    5G/4G spectrum sharing
    mmWave
    sub-6 GHz
    TDD
    SA (standalone)
    NSA (non-standalone)
    FDD
    Up to 1024-QAM
    100 MHz envelope tracking
    Adaptive antenna tuning
    800 MHz bandwidth
    8 carriers
    2x2 MIMO
    200 MHz bandwidth
    4x4 MIMO
    Uplink Data Compression (UDC)
    7x20 MHz carrier aggregation
    3x20 MHz carrier aggregation
    5G envelope tracking
    5G adaptive antenna tuning
    7.5 Gbps
    3 Gbps
    5G NR
    mmWave-sub6 aggregation
    sub-6 carrier aggregation (FDD-TDD, FDD-FDD, TDD-TDD)
    Dynamic Spectrum Sharing (DSS)
    mmWave
    sub-6 GHz
    TDD
    SA (standalone)
    NSA (non-standalone)
    FDD
    800 MHz bandwidth
    8 carriers
    2x2 MIMO
    200 MHz bandwidth
    4x4 MIMO
    5 Gbps
    5G NR
    mmWave
    sub-6 GHz
    TDD
    NSA (non-standalone)
    800 MHz bandwidth
    8 carriers
    2x2 MIMO
    100 MHz bandwidth
    4x4 MIMO
    Dual-layer polarization in downlink and uplink
    Beam tracking
    Beam steering
    Beam forming
