The premium-tier QRB5165 processor is designed to help you build smarter and powerful consumer, enterprise or industrial robots with on-device AI and 5G connectivity and more.
The QRB5165 brings the latest IoT technologies in a highly integrated chipset that powers the next generation of high-compute, AI-enabled, low power robots and drones for the consumer, enterprise, defense, industrial and professional service sectors that can be connected by 5G. The QRB5165 processor, customized for robotics applications, offers a powerful heterogeneous computing architecture coupled with the leading fifth-5th generation Qualcomm® Artificial Intelligence (AI) Engine delivering 15 Trillion Operations Per Second (TOPS) o...
Qualcomm Robotics Platform and Qualcomm Hexagon Tensor Accelerator, is a product of Qualcomm Technologies, Inc.
Features
- Qualcomm Spectra™ 480 Image Signal Processor designed to deliver a premium camera experience that can process 2 Gigapixels per second with high performance capture of 200 megapixel photos, 8K video recording and 4K HDR video capture.
- Adreno 650 Visual Processing Subsystem deliver’s quality graphics for larger-than-life immersive experiences using the Adreno graphics processing unit (GPU) and video processing unit (VPU).
- Hexagon 698 DSP with Hexagon Vector eXtensions (HVX), Hexagon Tensor Accelerator and Hexagon Scalar Accelerator to support sophisticated, on-device AI processing, and delivers mobile-optimized computer vision (CV) experiences for widearray of use cases.
- Qualcomm® Kryo™ 585 CPU: Manufactured in 7nm process node, optimized across four high-performance Kryo Gold cores and four low-power Kryo Silver cores.
- Qualcomm® Secure Processing Unit (SPU) offers vault-like security that is designed to help safeguard your facial data, iris scan and other biometric data. It supports hardware root of trust, Qualcomm® Trusted Execution Environment, Secure boot and camera security.
- Operating System: Ubuntu, Linux
- Qualcomm® Neural Processing SDK: optimizes deep learning processing performance across available resources to achieve superior edge computing experience
- Qualcomm® Computer Vision SDK offers a mobile-optimized computer vision (CV) library
- Enables new user experiences like gesture recognition, face detection, tracking and recognition, text recognition and tracking, and augmented reality.
- Hexagon DSP SDK: Designed to optimize the features and performance of multimedia software.
- Helps allow audio, imaging, embedded vision, and heterogeneous computing acceleration on the Hexagon DSP embedded in Qualcomm Technologies processors to create compelling multimedia user experiences
- Support for 12 cameras by D-PHY and 18 cameras by C-PHY (seven concurrent)
- Gen 3
Compare related products.
Note: to leverage the best experience for the product comparison table, please use the desktop to view content.
2 of 2 total products
Product | CPU Name | Number of Cores | Clock Speed | GPU Name | DSP Name | Wi-Fi Generation | Standards | MIMO Configuration | Bluetooth Specification Version | Display Number of Concurrent Displays | Interfaces Supported Interfaces | Software Options Operating System | Memory Speed | Type | Longevity Program Longevity Period | Process Node and Technology Process Node |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Qualcomm® Dragonwing™ Q5 Series | ||||||||||||||||
QRB5165 Active | Qualcomm® Kryo™ 585 | 8 | Up to 2.84 GHz | Qualcomm® Adreno™ 650 | Qualcomm® Hexagon™ | Wi-Fi 5 | 802.11ac | 2x2 | Bluetooth® 5.1 | 3 | USB 3.1 | Linux | 2133 MHz | LPDDR4x | 11 year(s) | 4 nm |
Other | ||||||||||||||||
Qualcomm® Kryo™ 385 | 8 | Up to 2.8 GHz | Qualcomm® Adreno™ 630 | Qualcomm® Hexagon™ 685 | Wi-Fi 4 | 802.11a | 2x2 | Bluetooth® 5.0 | — | — | — | 1866 MHz | LPDDR4x | — | 10 nm |
